Protection against electric shock Class I
Transformers and isolation
An internal isolation transformer is provided in
micro-inverter, internal transformer is galvanic
isolation from the MAINS and PV array by
reinforced insulation.
Certification TUV
Noise Level < 40 dB
Array residual
current detection
WARNING! An RCD with a residual current setting
of 30mA, located between the inverter and the
mains, shall be provided at the end-use
application! The RCD must be type B rather than
type A or type C
Array ground insulation
Resistance measurement-threshold
setting
The device is not provided with ground-fault
detector/interrupter unit.
Considered in the end-use system!
Operating temperature range -25
o
C～+65
o
C
Environmental
categories,
environmental
conditions
Outdoor (Outdoors, light weather protected,
mounted away from high temperature plant, and
no direct sunlight.)
In storage:
Temperature :–10°C to +65 °C;
Relative or absolute humidity: 5 % to 95 %
Air pressure: 86 kPa to 106 kPa.
During transportation:
Temperature : –25 °C to +70 °C;
Relative or absolute humidity: 5 % to 95 %
Air pressure: 70 kPa to 106 kPa
Dimensions (WxHxD) 235mmx144mmx53mm
Weight 2.9kg
