InWin A1 PLUS - Fan Specifications; Fan Model and Dimensions; Fan Electrical and Performance; Fan Connector and Lifespan

■ InWin products comply with RoHS regulation.
■ Specifications may vary based on different regions.
InWin Sirius Loop Fans
Model
Fan Size
Materials
Rated Voltage
Rated Power
Rated Current
ADD RGB Rated Voltage
ADD RGB Rated Power
ADD RGB Rated Current
Speed Mode
Air Flow
Air Pressure
Connector
Noise Level
Bearing Type
Life Expectancy
Sirius Loop ASL120
120 x 120 x 25mm
PBT
DC 12V
1.2W
0.1A
DC 5V
1.25W
0.25A
PWM 500-1800 RPM
50 CFM
1.67mm/ H2O
4-Pin
27 dB(A) Max.
Long Lifespan Sleeve Bearing
>30,000 hrs
