InWin A1 Prime - InWin 750 W PSU Specifications; PSU Performance and Safety; PSU Connector Breakdown

* InWin products comply with RoHS regulation.
* Specications may vary based on different regions.
Speci󽗉cations
Model P75F
Total Power 750W
Model Number IW-PS-PF750W
Materials SECC
Type ATX12V V2.52
Cable Management Non-Modular Cables
PFC Active PFC (> 0.95)
E󽗋ciency 80 PLUS® Gold (Up to 90%)
MTBF (Hours) > 100,000 hrs.
AC Input 100-240Vac, 8-10A, 50-60Hz
Fan 120mm Sleeve Bearing Fan
Typical Load Fan Noise(dBA) (50% Loading) < 25dBA
Operating Temperature Range (° C) 0-40 ° C
Full Protection OCP/ OVP/ UVP/ SCP/ OTP/ OPP
Safety Certi󽗉cations cTUVus / TUV / CB / CE / CCC / FCC / RCM / BSMI
Dimensions (L x W x H) 140 x 150 x 86mm
Warranty 5 Years
Connectors
20+4 Pin Motherboard 1
8-Pin CPU 1
8 (6+2) Pin PCI-E 2
SATA 3
InWin 750W 80PLUS Gold PSU
140 mm
150 mm 86mm
