WARNING
READ USER MANUAL
GUIDELINES
FOR INSTALLATION
Anti-tip over
floor support
TOOLS THAT YOU MIGHT NEED
3/8” (9.5mm) drill bit
for concrete and 1/8” (3mm)
drill bit for wood
electric or manual
Measuring tape
7/16” (11.1mm)
spanner for concrete and
5/16” (7.9mm) for wood
Pencil
Under certain circumstances, this refrigera-
tor can be tilted forward. Personal injury
may result. Install the anti-tip bracket includ-
ed with this refrigerator.
WARNING
If the fresh door is flipped over (reversible), the
anti-tip bracket must be installed by the autho-
rized service agent, in order to avoid a hazard.
Note: The anti-tip bracket must always be
positioned on the side opposite the door
hinge.
1
MEASURE THE SPACE WHERE
YOU WILL LOCATE THE
REFRIGERATOR
Measure the width of the space where your W
refrigerator will be located. Take into account
any protrusions such as the thickness of the
base or any space that may interfere with the
cabinet.
Note: this appliance is not intended to be
used as a built-in appliance.
Installation place:
Select the area to place your refrigerator. We
recommend a large, dry and well ventilated area.
The appliance should not be installed in such a
way that it receives direct sunlight, nor should it
be located near active heat sources such as kitch-
ens, heaters, etc…
1228 mm
1004 mm
Model ICO19JSPRSS
Model IWO19JSPFSS
W
W
1392 mm
1111 mm
Model INO27JSPFFS
W
1537 mm
1239 mm
6
