ION iCade mobile Service Manual

P/N Part Name Specification Q'ty
DR001470 ICG07(black)
ICG07(black)
20020077
top cover Polished, ABS
1
20030075
rear cover Textured, ABS
1
20630075
iPad passive dock Nylon,
1
20060019
battery compartment Textured, ABS
1
10330030
Spring
2
10520178
bead Stainless steel, plated
2
10230003
Steel post stainless steel
2
30170001
Silica gel pad rubber foot
1
30170002
Silica gel pad rubber foot
1
30170003
Silica gel pad rubber foot
2
20340050
Trim piece
ABS
2
20410064
Button ABS
4
20200043
switch cap ABS
1
10520177
steel plate stainless steel,T=1.0mm
1
30180002
iPhone mount Rubber,black
1
30180001
iPhone mount base Rubber,black
1
20410066
button 1 DN-PEB053,ABS(UL94-HB),grey(Pantone cool gray 7c),V1.0
1
20410065
button 2 DN-PEB052,ABS(UL94-HB),grey(Pantone cool gray 7c),V1.0
1
20410067
button 3 DN-PEB054,ABS(UL94-HB),grey(Pantone cool gray 7c),V1.0
1
20410068
button 4 DN-PEB055,ABS(UL94-HB),grey(Pantone cool gray 7c),V1.0
1
20410063
D-pad DN-PEB049,ABS(UL94-HB),grey(Pantone cool gray 7c),V1.0
1
20410071
E1 button DN-PEB058,ABS(UL94-HB),grey(PANTONE COOL GRAY 7C),V1.0
1
20410072
E2 button DN-PEB059,ABS(UL94-HB),grey(PANTONE COOL GRAY 7C),V1.0
1
20290028
bracket ABS
1
20110094
Lens PMMA ,Transparent,MT-11000
1
20410069
button 0 ABS
1
20410070
button 9 ABS
1
10350003
battery touch piece T=0.5mm,V1.0
2
10350004
battery touch piece T=0.5mm,V1.0
2
16010369
flat cable AN-W277,2P,32#,UL1571,L=15mm,
2
16010370
flat cable AN-W278,2P,32#,UL1571,L=15mm,
2
16040734
wire AN-W4301,30#,UL1571,10P,145mm,
1
16141005
multi-core cable
1P,UL1571,30#，red,120mm,
2
16141006
multi-core cable 1P,UL1571,30#,blue,150mm,
1
16141007
multi-core cable 1P,UL1571,30#,black,50mm,
1
12010108
Slide switch AN-S242,SS-12D00-G,
1
