ION iCade mobile Service Manual

70010469
screw Φ2*4mm,
2
70010010
screw Φ2.6*8mm,
8
70010740
screw Φ2.6*5mm,
4
70010054
screw Φ3*6mm,
1
70010742
screw M2*5mm,
1
70010739
screw M2*6mm,
1
CR010204 ICG07 MAIN
ICG07 MAIN ASSY
26020570
PCB AN-B20413,FR4Double panel,142*150*1.6mm,
1
18040165
LED AN-L0165,SMD-LED-0603,
1
50050276
ceramic capacitor 104,VDC16,±5%,X7R,0603,
1
50050323
ceramic capacitor 10UF,VDC10,+80/-20%,Y5V,0805,
2
11170374
resistor 1/10W,330Ω,±5%,0603
1
11170406
resistor 1/10W,10KΩ,±5%,0603
1
11170353
resistor 1/10W,10Ω,±5%,0603
1
11170429
resistor 1/10W,100KΩ,±5%,0603
1
18010143
diode MBR0520L,SOD123
1
14040836
IC ELM7527CBB-S,(2.7V)SOT23
1
40370310
Male connector AN-JP474,1.0-10AW,10P,white,SMD,
2
GR000261 ICG07(black)selective parts
ICG07(black)
60210005
BT module BPM20422,ION iCade Mobile,NUK13.015
1
60210006
BT module bluetooth module,BPM730,Ion iCade Mobile,NUK23.010,ICG07
1
50050133
ceramic capacitor 2.2UF,VDC10,±10%,X7R,0805,
1
90060086
safety sticker ICG07,50*18mm,Japanese use
1
90060084
safety sticker ICG07,52*35mm,Europe use
1
90280005
Voltage sticker 76*50mm,USA use,V1.0
1
90280006
Voltage sticker 76*50mm,UK use
1
90280007
Voltage sticker 76*50mm,Europe use
1
90280008
Voltage sticker 76*50mm,japan use
1
ER000370 ICG07(black) Packaging
ICG07(black)
23140012
blister pack transparent APET,268*95*50.5mm,T=0.4mm,ROHS,V1.0
1
23090389
Gift box 205g,273*100*55.5mm,ROHS,T=2.20mm,V1.0
1
23100236
inner box A3A,302*120*106mm,T=3.0mm,V1.0
1
23031000
carton box A3A,310*114*254mm,T=3.0mm,V1.0
1
23010509
PE bag PE,110*260*0.025mm
1
22010652
quickstart ICG07,English manual,V1.0
1
22010659
safety manual ION,safety manual,V14.4
1
90200056
Label BLACK&361Cprinting,Φ30mm,
1
22010658
keyboard setting manual ICG07,manual,V1.0
1
