ION IPTUSB User Manual

CONTROL PANEL FEATURES
POWER
PITCH
33
RPM
7845
+10%
-10%
TONE
LOW HIGH
AUDIO
OFF
1. Audio Level Control: This rotary control
adjusts the volume level of the onboard
speaker, headphone and line out outputs.
NOTE: Make sure the Audio Level Control is
set to OFF when connecting any alternate
audio output devices.
2. Tone Control: This feature allows you to
adjust the low and high frequency audio
levels.
3. Pitch Control: This knob adjusts the pitch of
the music +/- 10%. In the center position the
pitch is at 0%.
NOTE: In order for the pitch to be adjusted,
the tempo also changes according to what the
pitch setting.
4. RPM Selection Switch: This switch selects
the RPM of the turntable platter -- 33, 45, and
78 RPM.
5. Power LED: This LED indicates that the
power switch on. Make sure the power is off
when storing or transporting the unit, to avoid
wasting battery power.
BATTERY INSTALLATION
This product can be powered by 6 “D” Cell batteries. They should be loaded as show
above, with the positive end toward the handle.

ION IPTUSB Specifications

General

Type	Direct drive audio turntable
Operation	Manual
Plug and Play	Yes
Product color	White
Nominal speeds	33 1/3, 45, 78 RPM
Compatible operating systems	- Windows XP / Vista (32/64-bit) / 7 (32/64-bit) - Mac OS X 10.4
Power supply type	AC
USB version	2.0
USB ports quantity	1
Playback formats	MP3

Weight and Dimensions

Platter diameter	304.8 mm
