IOTA DLS SERIES User Manual

Distributed By:
TECHNICAL SPECIFICATIONS CHART
68357-027 REV 012512
IOTA ENGINEERING PO BOX 11846 TUCSON, AZ 85734 TEL: 1-800-866-IOTA (4682) FAX: (520) 741-2837 WEB: www.iotaengineering.com
DC Output Voltage (No Load) approx.
Output Voltage Tolerance (No Load)
Output Amperage, Max Continuous
Output Voltage (Full Load) approx.
Maximum Power Output, Continuous
Ripple and Noise
Input Voltage Range
Input Voltage Frequency
Maximum AC Current (@108Vac)
Typical Efficiency
Max Inrush Current, Single Cycle
Short Circuit Protection
Overload Protection
Line Regulation
Load Regulation
Fan Control
Thermal Protection
Working Temperature Range
Storage Temperature
Withstand Voltage (VDC)
*
Approximate Dimensions
Weight
27.2V (DC)
+ or - .5%
15 Amps
>27.0V (DC)
400 Watts
<100 mV rms
108 - 132 AC
47-63
7.3 Amps
>80%
30 Amps
Yes
>100%
100 mV rms
<1%
PROPORTIONAL
YES
0° - 40° C
-20° to 80° C
1700/1700/500
9.7″ x 6.7″ x 3.4″
4.5 lbs
27.2V (DC)
+ or - .5%
25 Amps
>27.0V (DC)
675 Watts
<100 mV rms
108 - 132 AC
47-63
12.2 Amps
>80%
30 Amps
Yes
>100%
100 mV rms
<1%
PROPORTIONAL
YES
0° - 40° C
-20° to 80° C
1700/1700/500
9.7″ x 6.7″ x 3.4″
5.0 lbs
DLS-27-15 DLS-27-25 DLS-27-40
27.2V (DC)
+ or - .5%
40 Amps
>27.0V (DC)
1100 Watts
<100 mV rms
108 - 132 AC
47-63
19.5 Amps
>80%
40 Amps
Yes
>100%
100 mV rms
<1%
PROPORTIONAL
YES
0° - 40° C
-20° to 80° C
1700/1700/500
13″ x 6.5″ x 3.4″
7.8 lbs
SERIES M
RATINGS AND SPECIFICATIONS
*
Primary to Chassis/Primary to Secondary/Secondary to Chassis
SERIES M

IOTA DLS SERIES Specifications

General

Dimensions	Varies by model
Weight	Varies by model
Absorption Voltage	14.4 VDC (for 12V models)
Charging Stages	Bulk, Absorption, Float
Protection Features	Over Voltage Protection, Over Current Protection, Short Circuit Protection
Compatibility	Lead-acid, AGM, Gel
Output Voltage	12/24/48 VDC
Cooling	Fan Cooled (depending on the model)
