Kit Includes:
• 10 Amp Fuse Saver Protection Handle,
Red (#8005-10A)
• 15 Amp Fuse Saver Protection Handle,
Blue (#8005-15A)
• 20 Amp Fuse Saver Protection Handle,
Yellow (#8005-20A)
• Dual Sided Fuse Box Connector Cable (#8005-7)
• Blow-Molded Case
PREPARATIONS FOR USE
Before inserting the Fuse Adapter into the fuse box:
• Read all warnings.
• Disconnect the negative battery terminal on the vehicle.
• Determine which circuit you want to test and what amperage rating the manufacturer
requires for this circuit. (Verify proper fuse size by checking the vehicle’s owners manual.)
• Remove and inspect the fuse, as well as the fuse connection identified as the troublesome
circuit. Do not use the tool if a meltdown is found at the fuse terminal connection.
• Verify that the connection for the fuse is free from corrosion and that the plastic insulation of
the fuse box is not blistered or deformed from heat. (If this is the case, replace fuse box and
internal connectors before proceeding.)
• Always install #8005-7 Fuse Box Connector Cable with the breaker handle connected.
• Select a breaker which matches the manufacturer’s amperage requirement for the specific
circuit to be tested and connect it to the female end of the Fuse Box Connector Cable.
Handles are color coded for easy selection.
SPECIFICATIONS
Operating Voltage: 10 - 14V DC
Operating Temp: 40°F - 110°F
Fuse Box Connector: 3.7" with 10 ft. Zip Cord (8005-7)
Overload indicator: White Open Indicator
Interrupting Characteristics: @ 77°F
2
LOAD %
100%
135%
200%
400%
1000%
TRIP TIME
NO TRIP
< 1 Hour
2.2 - 12 Seconds
.55 - 1.2 Seconds
.12 - 3 Seconds
Cased Product Weight: 2 Lbs
Cased Dimensions: 12" (L)x 9.5" (W) x 2" (H))
Available Separately:
• 5 Amp Breaker Handle (#8005-5)
• 30 Amp Breaker Handle (#8005-30)
• BuzzAlert
TM
Alert Module (#8011)
• Additional 10 Ft. Extension Power Cord
(#8005-EXT)
• Fuse Box Adapter Kit (#8014)
