GB
CT45 TECHNICAL SPECIFICATIONS
CT45 B CT45 BT CT45 C
Cleaning width mm 500
Squeegee width mm 730
Cleaning capacity per hour m
2
/h 1750
Number of brushes n° 1
Brush diameter mm 500
Maximum brush pressure g/cm
2
/
Brush rotation speed g/1° 160 140
Brush motor power W 400 450
Drive motor power W 180
Maximum speed Km/h 3,5
Suction motor power W 550 400
Solution tank L 40
Dirty water tank L 45
Rear wheel diameter mm 250
Maximum slope % /
Gross weight Kg 140 145 105
Transported weight Kg 88 88 40
Number of batteries n° 2
Battery voltage V 12
Individual battery capacity Ah (5h) 74 /
Power system voltage V 24
Machine dimensions mm
X=980
Z=1290
Z1=806
Y=715
Battery compartment dimensions
(length, width, height)
mm 265x335x255 /
Packed size (length, width, height) mm
Sound pressure
LpA
(dB)
69 / 80
Measurement uncertainty
K
(dB)
///
Vibration level (hand)
HAV
m/sec2
1/1
Measurement uncertainty, k m/sec2 0,5 / 0,5
8
