1．Checktoseeifanyboltsornutsareleftuntightenedorloose.
2.Periodicallycheckallboltsandnutstoseeiftheyareloose,andretightenifneeded.
2656 KURAGANO-MACHI TAKASAKI-CITY GUNMA-PREF 370-1201 JAPAN
Checkafterinstallation
Awning
ARBSideAwningmountingholes
3.Aftersecuringyourawning,fitthenutcaps
ontohexbolts,nutsandwashers.
Pleaserefertotheinstructionsofyour
awningforthelengthofoverhang.
Awningsfitting
Rhino-RackAwningmountingholes
UsethreeM6holesoneachstay
UsetwoM8holesoneachstay
ForARBSideAwnings(PVCbag)
ForARBSideAwnings(PVCbag)
ForRhino-RackSunseekerAwningsForRhino-RackSunseekerAwnings
Note
Note
Recommended tightening torque for nuts : 10 N-m
☆
☆
・Pleaserefertotheinstructionsfor
・ fittingyourawning.
・Usetheboltsandnuts(⑥-⑩)to
・ attachtotheAwningstayinthecenter.
Awningstayinthecenter
Awning
Overhang
Overhang
Nut
Nutcap
