Washer-Extractors
34
5-08-51
Machine Dimensions - IWF075 (2-speed)
1 Hard Water Connections .75 in. 6 Electrical Connections
2 Warm Water Connections .75 in. 7 Drain Valve
3 Soft Water Connections .75 in. 8 Steam Connections
4 Main Switch 9 Liquid Soap Connections
5 Ventilation Tub 10 Ventilation Soap Dispenser
Figure 19
CHM2131N
CHM2154
CHM2153N
55.57 in. (1412 mm)
54.59 in. (1387 mm)
2.64 in.
(67 mm)
9.76 in.
(248 mm)
33.46 in. (850 mm)
2.76 in.
(70 mm)
19.69 in.
(500 mm)
38.98 in. (990 mm)
2.76 in.
(70 mm)
0.26 in.
(7 mm)
43.8 in. (1113 mm)
22.44 in.
(570 mm)
13.66 in.
(347 mm)
40.55 in. (1030 mm)
41.54 in. (1055 mm)
CHM2154N
CHM2153N
CHM2131N
1.81 in.
(46 mm)
19.21 in.
(488 mm)
14.47 in. (368 mm)
9.72 in. (247 mm)
49.61 in. (1260 mm)
46.02 in. (1169 mm)
10.39 in.
(264 mm)
12.22 in.
(311 mm)
40.3 in.
(1024 mm)
4.53 in.
(115 mm)
10.55 in.
(268 mm)
3.86 in.
(98 mm)
10
1
3
7
5
2
6
8
9
4
2.81 in.
(71.5 mm)
7.36 in. (187 mm)
