IPSO HC75 - Page 9

9
1202
1175
66
780
64866
34 34
475
HC135 = 816 - HC165 = 916
HC135 = 760 - HC165 = 860
HC135 = 665 - HC165 = 765
82
36.5
88
36.5
220
530
893
935
968
267
202
105
L
B
D
C
332
A
E
1008
60
200
K
200
155
I
H
G
F
35
70
Dimensions
2
HC135 - 165
 A. Ventilation soap dispenser
 B. Liquid soap connetions
 C. Hard water connections 3/4"
 D. Warm water connections 3/4"
 E. Soft water connections 3/4"
 F. Connections clamps
 G.Electrical connections
 H.Emergency button
 I. Ventilation tub
 K. Drain valve
 L. Steam connections
