IPSO WE176 - 2 Technical Data and Dimensions; Technical Data

4
2
Technical data and dimensions
Technical data
WE 176 WE 234
Capacity (dry weight)
1/11 16 kg 21,3 kg
1/10 17,6 kg 23,4 kg
1/9 16,1 kg 26 kg
Cylinder
Diameter 750 mm 750 mm
Depth 399 mm. 530 mm
Volume 176 Lit. 234 Lit.
Cabinet
Height 1505 mm 1505 mm
Width 900 mm 900 mm
Depth 800 mm 930 mm
Front loading
Diameter door opening 395 mm 395 mm
Door height 510 mm 510 mm
To center 750 mm 750 mm
Speed
Wash 45 rpm
Spin 425 rpm
G-force
Spin 76
Motor(3 phase)
Wash 18p. 290rpm 280 W 400 W
Spin 2p. 2900 rpm 1300 W 2000W
Drain valve
Depend-O-Drain 3"
Water supply
Hard, soft, warm water and cool-down 3/4"
Steam connection
Steam connection 3/8"
Heating
Electrical 220/380 V 12/15/18 kW
Electrical 380 V 12/15/18/21/24 kW
Steam X
Warm water (without additional heating) X
Warm water (with additional heating) X
Packing dimensions
(H x W x D) 1105x975x1535 mm
Weight
Net 400 kg 435 kg
Gross 485 kg 500 kg
