-7-
CURRENT INPUTS
-8-
SPECIFICATIONS
INPUT SIGNAL
Options
4-20mA
0-20mA
0-5V DC
1-5V DC
0-10V DC
or to customer order
INPUT IMPEDANCE 4-20mA/0-20mA 250ohm
other values to order
0-5V/1-5V/0-10V >250kohm
RELAY RATING 10A 400V 2500VA
10A 30V DC
POWER SUPPLY
Options
110V 50/60Hz.
230V 50 Hz.
POWER CONSUMPTION 4VA approx. (old models 6VA).
TEMPERATURE LIMITS -5/+60°C
HUMIDITY LIMITS 0-90% RH
non condensing
SETTING ACCURACY 5% Typical
REPEATABILITY < 0.5%.
