PRODUCT DIAGRAM
SILICONE PAD
LASER
LED
SILICONE PAD
SAFETY SENSOR
CONTROLLER
DC 5V POWER ADAPTER
POWER WIRE
Description Function
Dome Housing
Power Cord
Controller
Silicone Pad
Light Emitting Diode (LED)
Laser Diode
Safety Sensor
Plastic dome congured with 300 lasers and 200 LEDs to provide
low-level light therapy treatments to the scalp*
Connect device and controller
External system control to operate on/off, built-in timer and start/pause
Padding around the protective shield to increase comfort
200 LEDs are the light sources for treatment*
300 lasers are the light sources for treatment
An electronic sensor that permits use of the iRestore Elite only
when it is placed on the head in the recommended position
1
2
3
4
5
6
7
*300 Class 3R Lasers (<5mW), 100 LEDs (625nm), and 100 LEDs (655nm)
