Video Distribution
Amplifier
IRISVDA0208
RS485 Serial
Data Distributor
IRISEXP0204
Fig:2.0. Slightly more complex set up with 4 IRIS106 cameras being
controlled and viewed at 2 separate helm positions. Data from each
controller is fed into the input of the RS485 Serial Data Expander, and
data to each camera is connected to the outputs. This keeps the data
‘clean’ and prevents data cross talk and over-runs. Video from each
camera is fed into a VDA (Video Distribution Amplifier), which feeds two
MFD’s. Power not shown to keep diagram simple.
