11
Section 5
Appendix
Specifications
Product Number
SSX3
Model Number
M502-22
Spin Parameters
2 min: 120 seconds @ 7200 rpm / 4440 xg
3 min: 180 seconds @ 7200 rpm / 4440 xg
5 min: 300 seconds @ 5600 rpm / 2685 xg
Acceleration Time
≤ 25 seconds
Deceleration Time
≤ 30 seconds
Electrical
100 – 240 VAC, 50/60Hz, 3.0 Amps
Dimensions
Height: 7”
Width: 11”
Depth: 10”
Weight: 8¾ lbs.
Environmental
For indoor use only
Ambient temperature 2ºC to 40ºC
Maximum 80% RH between 2ºC and 30ºC,
decreasing to 50% RH at 40ºC
Maximum altitude 2000 m
Main supply voltage fluctuations should not exceed ±10%
Transient over-voltages according to installation category II
Pollution degree 2
Specifications are subject to change without notice.
WARNING – Do not operate or store the Express 3 or its rotor below the 2
o
C
minimum operating temperature. At extreme low temperature (below -18
o
C) the rotor
material is subject to cracking under impact stress (such as dropping onto a hard
surface).
