Ironman4x4 INSTANT AWNING - Installation Guide

2 - 9
Thank you for purchasing an Ironman 4x4 Instant Awning.
Your Ironman 4x4 Instant Awning is designed to fit a variety of different roof rack styles. The
following User Guide will help you adapt your new Instant Awning to suit your application.
INSTALLATION
IMPORTANT: Before mounting your Instant Awning make sure that it clears the
door openings, lift up tailgate, aerials or other obstructions on the vehicle.
• Insertboltheadsintotheslotsinthealuminiumextrusion.
NOTE: Your Instant Awning can be mounted directly to the side of a roof cage by simply drilling four
6.5mm holes into the side supports and attaching using the bolts and nyloc nuts supplied.
Alternatively, you can use the supplied ‘L’ brackets and mounting hardware in the various
configurations shown below.
