Ironton 54126 - User Manual

Questions and Answers

T
Tyler TylerAug 10, 2025
Why does my Ironton Winches motor run slowly?
- H
  Heather BarrettAug 10, 2025
  If your Ironton Winches motor runs slowly or lacks normal power, it could be due to insufficient current or voltage, loose or corroded battery cable connections, or incorrect power cords. Try these solutions: 1. Recharge a weak battery and run the winch with the vehicle motor running. 2. Clean, tighten, or replace any loose or corroded battery cable connections. 3. Ensure you are using only the supplied power cords.
J
jenniferdavisAug 16, 2025
How to prevent my Ironton 54126 Winches motor from overheating?
- P
  Pamela PhillipsAug 16, 2025
  The Ironton Winches motor may overheat due to incorrect power cords or running the winch for too long. To resolve this, use only the supplied power cords and allow the winch to cool down periodically.
D
David BrownAug 22, 2025
What to do if my Ironton 54126 motor runs in one direction only?
- B
  Brianna MorrisAug 22, 2025
  If your Ironton Winches motor only runs in one direction, the cause may be a defective or stuck solenoid or a defective switch assembly. Try tapping the solenoid to loosen the contacts. If that doesn't work, repair or replace the solenoid or replace the switch assembly.
E
Erin GonzalezAug 27, 2025
What to do if the motor runs but the wire rope drum does not turn on my Ironton Winches?
- L
  Logan AlvaradoAug 28, 2025
  If the Ironton Winches motor runs, but the wire rope drum doesn't turn, it might be because the clutch is not engaged. Move the Clutch Handle to the Engaged position. If the problem persists, contact a qualified technician to check and repair the unit.
R
Robert FreemanNov 3, 2025
What to do if the motor on my Ironton 54126 does not turn on?
- M
  Mary LynchNov 3, 2025
  If the Ironton Winches motor doesn't turn on, here's what to check: * Ensure the switch assembly is fully inserted into the connector. * Tighten all nuts on the cable connections. * Charge the vehicle battery completely. * Try tapping the solenoid to free the contacts, and directly apply 12 volts to the coil terminals to check for activation (a clicking sound indicates it's working). * If these steps don't resolve the issue, you may need to replace the switch assembly or check for voltage at the armature port when the switch is pressed. If voltage is present, the motor may need replacement. Also, ensure that water didn't enter the motor and allow it to drain and dry, running it in short bursts without load until completely dry. If the problem persists, have a technician service ...
