IrriGreen Irrigreen2 - Optional Flow Sensor Wiring; Connecting Flow Sensor to Controller

Red Flow Sensor lead to
Controller Terminal“Sen1”
Black Flow
Sensor lead
to“Common”
35
Optional Flow Sensor Wiring to Controller
Red Flow Sensor lead to “Sen1”
Black lead to “Common”
