2 - WIRING DIAGRAM - 412100770100
BT1 ROOM PROBE BT2 EVAPORATOR PROBE BT3 CONDENSER PROBE BT4 PRODUCTS PROBE C1/2 CAPACITOR CE1 CONTROL MODULE CE2 CONTROL MODULE EH2 COLD-STORE DOOR FRAME HEATING RESISTOR EV1 CONDENSER FAN EV2 EVAPORATOR FAN
KA1 COMPRESSOR RELAY MS1 COMPRESSOR S1 PRESSURE SWITCH SQ1 REED SWITCH T1 TRANSFORMER 220V-24V YV1 DELIVERY SOLENOID VALVE YV2 DEFROSTING SOLENOID VALVE LS STERILIZER LAMP QF1 THERMAL SWITCH KM1 COMPRESSOR CONTACTOR
