Rothan www.islabikes.co.uk
1. Brake levers
2. Brake pads
3. Saddle
4. Seatpost
5. Seatpost clamp
6. Stem
7. Stem bolts
8. Headset
1. Turn handlebars clockwise and align with front wheel
2. Tighten stem clamp bolt max 7Nm
Failure to correctly tighten stem clamp bolt may result
in serious injury or death. If in doubt, please consult our
technical support team on +44 (0)800 008 6297
or email techsupport@islabikes.co.uk.
9. Headset spacers
10. Headset adjuster bolt
11. Handlebars
12. Rim
13. Spokes
14. Tyres
15. Frame
16. Fork
Step 1 of 2
Handlebar set up
6
1.Turn
Do Not
Tighten
2.Tighten
Your Rothan must be assembled and checked by a suitable
adult using the steps detailed in this owner’s manual.
5
4
10
1
8
7
9
11
14
12
15
2
16
13
3
To Next Page
