21 ABA00160
Rotor shaft 轉子心軸
20x275L
1
22 ADD0075D
Rotor 轉子 61x75
1
23 AHA00011
Magnetic iron 磁鐵 R29.4x9.4x36.5x42.5
8
24 BBD51000
Shrink pipe 收縮帶 95x100
1
25 AGG63020
Bearing 培林軸承 6302-LLB
1
26 ACM00090
Cable bushing 出口線塞
1
27 BBD4002A
P.V.C Insulation tubing ( gray) 灰色套管
1
28 AGH63020
Preload spring 培林彈簧 #6302
1
29 BBK00040
Stator solenoid ASM. 定子組
1
30 AGA06080
Stator fixing screw 定子固定螺絲 M6x6L
1
31 AGA0515B
Screw +Spring washer +Washer
螺絲+彈簧華司+平華司
M5xS5x2.5T15x15L
4
32 AAA30272
Motor housing 中管
1
33 AGA0510C
Ground copper screw 地線銅螺絲 M5x10L
1
34 AGC00050
Spring washer 彈簧華司 S5
1
35 AGB05120
Washer copper 平華司
12 x 5 x t0.8
1
35 CJA50421
Plug 插頭
1
37 CJA5049A
Cap 披套
1
38 BBF23206
Ground 地線
1
39 SNSP0020
Screw ASM. 螺絲包
1
40 ABA00031
Adjusting screw ASM. 底座鉤螺絲組
8.9x130L
1
41 AGE10080
Nut 螺帽 M10x t8
2
42 AGC00100
Spring washer 彈簧華司 S10
1
43 AGB10020
Washer 平華司
21 x 10 x t1.5
2
44 AGA0512D
Screw 圓頭螺絲 M5x12L
1
45 AAA0011A
Slide base 底座
1
46 ABA00180
Lateral pin 底座橫心
10x70L
1
47 ADA00560
Wave ring 三波彈簧墊片 Bww608
1
48 SNSA003B
Inside pulley cover ASM. 皮帶輪內蓋組
1
49 AAAP100B
Motor pulley100
皮帶輪100
100
1
50 AGM04130
Key 半圓鍵
13xH5xW4x12.6L
1
51 AGC0010B
Spring washer 彈簧華司 S10x t2.5
1
52 AGE1008C
Nut 螺帽 M10xP1
1
53 SNSA003E
Outside pulley cover ASM. 皮帶輪外蓋組
1
54 ACA0010A
Dropping Plate 皮帶輪止落板
1
55 ACA00380
Outside pulley cover 皮帶輪外蓋
1
56 AGA05080
Screw +Spring washer 螺絲+彈簧華司
M5xS5x8L
2
57 ACA00090
Dropping Pad 皮帶輪止落墊
1
58 ACB0012A
Dropping bolt (big) 皮帶輪止落螺栓(大)
1
