INTRODUCTION
1-1 Unpacking and Inspection
Upon removing your new current transducer
from it's packing , you should have the following
items:
1. Current Transducer with coiled cable out put
plugs.
2. Instruction manual.
3. Carrying Case.
1-2 Front View
Refer to Figure 1 and the following numbered
steps to familiarize yourself with the transducer.
1. Transformer Jaws — Designed to pick up the
a.c. current following through the conductor.
2. Hand Guard — Designed to protect user for
safety.
3. Trigger — Press the lever to open the trans-
former jaws.
