Isokern MAGNUM 36 - Assembled Firebox Dimensions 60 & 72

10
Assembled Firebox Dimensions - Models 60 & 72
Model
Minimum Framing
60”
76 1/2” W x 87 1/2” H x 29½” 2500 lbs.
72”
B
28”
28”
D
41”
41”
H
25 ¼”
25 ¼”
I
4 3/4”
4 3/4”
J
5”
5”
K
8”
8”
TOP PLATE
Part
No.:
M77
Fireplace
Size:
60” W
Quantity:
2
25 ¼”
11”
4
¾
”
N
M
Right Section Front Elevation
Top Plan View
Plan Section
F
69 3/4”
57 1/4”
M
14 1/4”
14 1/4”
N
11”
11”
32 3/
4”
A
85 1/2 ”
73 1/2”
C
85 3/4 ”
85 3/4”
E
69”
G
55 1/2“
65 1/2”
C
D
H G
I
K
F
E
E
B A
J
B
M77 72” W 2
81 1/4”
Weight
88 1/2” W x 87 1/2” H x 29½” 2900 lbs.
O
55 1/2”
65 1/2”
O
