Isomac ALBA - Componenti Della Macchina; Accessori

1 Interruttore generale
2 Led macchina accesa (Colore Rosso)
2 Spia macchina accesa (Colore Rosso)
3 Led resistenza (Colore Rosso)
3 Spia resistenza (Colore Rosso)
4 Led Caffè (Colore Verde)
4 Spia erogazione caffè (Colore Verde)
5 Led livello "MAX" acqua serbatoio
(Colore Verde)
6 Led livello "MEDIO" acqua serbatoio
(Colore Verde)
7 Led livello "MIN" acqua serbatoio
(Colore Rosso)
8 Portafiltro
9 Scaldatazze
10 Gruppo erogazione caffè
11 Cassetto raccogligocce
con griglia per appoggio tazze
12 Leva erogazione caffè
13 Manopola erogazione vapore
14 Lancia erogazione vapore
15 Manopola erogazione acqua calda
16 Lancia erogazione acqua calda
17 Manometro pressione caldaia
18 Manometro pressione pompa in erogazione
1.1 Accessori
• Portafiltro a due tazze
• Portafiltro ad una tazza
• Pressino
• Misurino
ALBA
TEA
ALBA
TEA
TEA
ALBA
ALBA
ALBA
1. COMPONENTI DELLA MACCHINA
ALBA
5
ALBA
-
TEA
1 Main switch
2 Machine on LED (red)
2 Machine on light (red)
3 Heating element LED (red)
3 Heating element light (red)
4 Coffee LED (green)
4 Coffee distribution light (green)
5 Tank "MAX" water level LED (green)
6 Tank “MEDIUM” water level LED (green)
7 Tank "MIN" water level LED (red)
8 Filter holder
9 Cup warmer
10 Coffee distribution unit
11 Drip tray with cup rack
12 Coffee distribution lever
13 Steam knob
14 Steam nozzle
15 Hot water knob
16 Hot water nozzle
17 Boiler pressure gauge
18 Distribution pump pressure gauge
1.1 Accessories
• Two cup filter holder
• One cup filter holder
• Presser
• Measure
ALBA
TEA
ALBA
TEA
TEA
ALBA
ALBA
ALBA
1. PARTS OF THE MACHINE
ALBA
1 Interrupteur général
2 DEL machine en marche (Couleur Rouge)
2 Témoin lumineux machine allumée
(couleur Rouge)
3 DEL résistance (Couleur Rouge)
3 Témoin lumineux résistance (Couleur Rouge)
4 DEL Café (Couleur Vert)
4 Témoin lumineux distribution café (Couleur Vert)
5 DEL niveau "MAX" eau réservoir (Couleur Vert)
6 DEL niveau "MOYEN" eau réservoir
(Couleur Vert)
7 DEL niveau "MIN" eau réservoir
(Couleur Rouge)
8 Porte-filtre
9 Chauffe-tasses
10 Groupe distribution café
11 Tiroir de récupération gouttes avec grille pour
appui tasses
12 Levier distribution café
13 Poignée distribution vapeur
14 Lance distribution vapeur
15 Poignée distribution eau chaude
16 Lance distribution eau chaude
17 Manomètre pression chaudière
18 Manomètre pression pompe de distribution
1.1 Accessoires
• Porte-filtre deux tasses
• Porte-filtre une tasse
• Presse-café
• Doseur
ALBA
TEA
ALBA
TEA
TEA
ALBA
ALBA
ALBA
1. COMPOSANTS DE LA MACHINE
ALBA
