Engine Control System 1A-177
DTC118 - Common Rail Pressure Fault (Control System)
Legend
1. Fuel tank
2. Fuel filter
3. Supply pump
4. SCV (suction control valve)
5. FT (fuel temperature) sensor
6. Common rail
7. Common rail pressure sensor
8. Injector
9. ECM (engine control module)
LNW21AMF005401
2
3
1
6
7
9
8
5
4
