4-25
CONTROLS AND INSTRUMENTS
Warning and indicator messages are shown on the MID to alert you to system failures
or prompt you to necessary checks you should perform while operation-related
information is being displayed.
Use the MID select knob to select the desired screen page or function.
Display indication Color Descriptions
Reference
page
Amber Fuel level is too low. 4-58
Red Water needs to be drained from fuel filter. 4-48
Red Engine overheated 4-42
Red Power take-off (PTO) is in operation. 4-65
Red Cab tilt lock is not engaged. 4-59
Red Meter has a problem. 4-68
Red
Error in communication between instrument
and connected systems.
4-68
Amber Engine oil level is too low. 4-44
Amber
Air cleaner needs cleaning soon.
4-45
Warning and Indicator Lights Display
