4-41
CONTROLS AND INSTRUMENTS
Engine Oil Pressure Warning Light
This warning light should come on when
the starter switch is turned to the "ON"
position, and then should go out after the
engine is started.
While the engine is running, this warning
light comes on if the engine oil pressure,
which lubricates the engine components, is
abnormal.
ADVICE
If this warning light comes on while the engine is running, immediately pull off to
a safe place well clear of traffic.
The lubrication system may be faulty. Promptly have your vehicle inspected at
the nearest Isuzu Dealer.
•
•
Engine Oil → Refer to page 7-31
Engine Over Run Warning Light
V
This warning light comes on and a beep
sounds when the tachometer needle goes
into the red zone.
Tachometer → Refer to page 4-13
4608498sec04CONTROLSANDINSTR4-414-414608498sec04CONTROLSANDINSTR4-414-41 2015/11/0213:58:432015/11/0213:58:43
To Next Page
