4-156
CONTROLS AND INSTRUMENTS
Warning of HSA
The HSA indicator light comes on or flashes and a buzzer sounds to give a warning in
the following cases.
Condition and alarm type
HSA
indicator
light
Buzzer Action
A door is opened without pulling
the parking brake while the HSA
is activated.
Flashes
Short,
repeated
beeps
Pull up the parking brake
lever and then open the
door.
Too long activation warning.
The vehicle is stopped a long
time with the HSA activated.
Flashes
Short,
repeated
beeps
Use the parking brake for
stopping or further depress
the brake pedal.
Vehicle movement warning.
The vehicle starts moving from a
stopped position even though the
HSA is activated.
Flashes
Continuous
beep
Failure warning.
The HSA indicator light and
buzzer are activated.
Flashes
Short,
repeated
beeps
Stop the vehicle safely and
deactivate the HSA using
the HSA OFF switch.
Flashes —
Comes
on
Continuous
beep
Starter switch "LOCK" warning.
The starter switch is placed into
the "LOCK" position without
pulling the parking brake.
Goes
out
Short,
repeated
beeps
(lasts up to 30
seconds)
Pull the parking brake lever.
CAUTION
When a failure warning is issued, the HSA system is faulty. Have your vehicle
inspected at the nearest Isuzu Dealer as soon as possible.
•
NOTE
A buzzer sounds when you open the door without pulling the parking brake
lever with HSA activated.
When you park the vehicle in gear without pulling the parking brake lever in
order to park in cold regions, a buzzer will sound for about 30 seconds. This
does not indicate any abnormal condition.
•
•
Parking in Cold Regions
→ Refer to page 6-20
