4-191
CONTROLS AND INSTRUMENTS
The freewheel hubs are devices that allow the front wheels and the drive shaft to be
manually connected and disconnected.
Freewheel Hub
V
CAUTION
Whenever driving in 4WD mode, confirm that the knobs on the freewheel hubs
are set to the "LOCK" position.
If they are free, excessive torque will be exerted on the rear driving system
when switching to 4WD low range, possibly causing damage.
On a part-time 4WD model, do not press the 4WD switch when driving with the
knobs on the freewheel hubs in the "FREE" position. Doing so could cause the
transfer case to fail.
•
•
ADVICE
Do not set the knobs midway between the "FREE" and "LOCK" positions.
In order to ensure sufficient lubrication of the front-wheel drive system, drive
approximately 20 km (12 miles) every month with the left and right freewheel
hubs in the "LOCK" position.
The knob of the left and right freewheel hubs can become hot after driving.
Whenever setting the freewheel hub in the "LOCK" or "FREE" position, always
do so on both sides of the vehicle.
•
•
•
•
"FREE" Position
When a freewheel hub's knob is in the
"FREE" position, the wheel is disconnected
from the drive shaft.
This position should be used for driving in
2WD mode.
