CONTROLS AND INSTRUMENTS
NOTE
Whenever driving in 4WD mode,
ensure that the knobs on the left and
right freewheel hubs are set to the
"LOCK" position. (Even when the
4WD switch is turned "ON", driving
in 4WD mode is possible only when
the knobs on the freewheel hubs
are set to the "LOCK" position.)
If the left and right freewheel hubs
are set to the "FREE" position and
the front wheels are disconnected
from the drive shaft during driving
in 2WD mode, rotation of the front
wheels will not be transferred to the
front drive system. As a result, noise
and friction levels can be reduced
for more economic driving.
•
•
"LOCK" Position
When a freewheel hub's knob is in the
"LOCK" position, the wheel is connected to
the drive shaft for 4WD operation.
This position must be used for driving in
4WD mode.
