4-194
CONTROLS AND INSTRUMENTS
PTO Switch
Engaging PTO on a Smoother Model
1. Set the parking brake and place the gearshift lever into the "N" position, and
return the idling control knob to the fully counterclockwise position.
2. Depress the brake pedal, press the PTO switch to the "ON" position, and make
sure that the PTO indicator light comes on (standard model) or is displayed (model
with MID).
This is a switch to engage and disengage the PTO. When PTO is engaged, the PTO
indicator light comes on (standard model) or is displayed (model with multi-information
display (MID)).
When engaging the PTO, be sure to stop the vehicle before operating the switch.
CAUTION
Be sure to disengage the clutch
before operating the PTO switch;
otherwise damage to the gears will
result.
•
Engaging PTO on a Manual
Transmission Model
1. Set the parking brake and place the
gearshift lever into "N".
2. Fully depress the clutch pedal, pause
for a moment, and press the PTO
switch to the "ON" position. Make sure
that the PTO indicator light comes on
and gently engage the clutch.
Model with MID
PTO indicator light
Standard model
