4-197
CONTROLS AND INSTRUMENTS
To Lower the Dump Body
Move the lever down while pressing the
push button.
Mixer Control Lever
Mixing, charging and discharging take place by placing the control lever into the
relevant position. The drum rotation speed can be adjusted by changing the accelerator
pedal position.
NOTE
For handling and more detailed instructions about the dump body, please refer
to the dump body manufacturer's Instruction Manual.
•
NOTE
For handling and more detailed instructions about the concrete mixer, please
refer to the concrete mixer manufacturer's Instruction Manual.
•
CAUTION
Be sure to lock the lock lever while driving.
Release the lock lever when charging and discharging.
•
•
