4-198
CONTROLS AND INSTRUMENTS
The seat belt with pretensioner and SRS airbag system is activated in the event of
a frontal collision when the impact energy exceeds a certain level to help lessen the
shock on the head of the driver or passenger (a model with a passenger side airbag)
by firmly restraining the body of the occupant in the seat with the seat belt with
pretensioner and airbag. Be sure to observe the following instructions to prevent you
and your passenger from suffering a serious or fatal injury due to shocks resulting from
the seat belt with pretensioner and airbag operation.
Operation Check
The SRS airbag warning light should
flash seven times when the starter switch
is turned to the "ON" position, and then
should go out.
If the SRS airbag warning light stays on,
the airbag (including the passenger airbag,
if equipped) may not function properly
when needed.
CAUTION
If an error occurs, have your vehicle
inspected/serviced at your Isuzu
Dealer as soon as possible.
[Error]
If the warning light does not flash
seven times when the starter
switch is turned to the "ON"
position.
If the warning light does not go
out.
If the warning light comes on
while driving the vehicle.
•
-
-
-
Seat Belt with Pretensioner and Supplemental Restraint
System (SRS) Airbag System
V
Airbag assembly for driver seat
