= Avoid overloading your sander. It will become hot and lose efciency.
Running it free of load for a minute or two will allow it to cool itself to normal
temperature.
= Inspect the cord regularly and have it replaced by an authorized repair facility
if it is damaged.
= Lubrication for this tool is done at the factory and should not be necessary
again under normal use.
= Check the sanding disc regularly for tears, cracking, and other damage. A
damaged disc can allow the pad beneath to be damaged, particularly the
hooks.
NOTE: Because of the operator vigilance required in this respect, the pad is
considered a consumable part and is not covered under warranty.
= An authorized repair centre should do any repairs, modication, or
maintenance that involve disassembling the sander.
= Any damage to the tool should be corrected at an authorized repair centre.
PARTS LIST
Please refer to the schematic drawing on page 11.
MAINTENANCE
N
O.
DESCRIPTION
1 Switch cover
2 Switch
3 Label
4 Screw ST. 4.2 x 19
5 Right housing
6 Dust bag assembly
7 Speed dial switch
8 Screw ST. 4.2 x 14
9 Anchor
10 Cord guard
11 Cord
12 Stator
13
Carbon brush
14
Left housing
N
O.
DESCRIPTION
15 Label
16 Bearing 608Z
17 Armature
18 Bearing 629Z
19 Fan
20 Bearing cover
21 Bearing 6002Z
22 Washer
23
Spring pin
24
Screw M5 x 15
25
Dust cover
26 Sanding pad
27 Screw M5 x 12
