PRODUCT NO. 024852 • ITC IPT-55A PALLET TRUCK
REF PART NUMBER DESCRIPTION REQ REF PART NUMBER DESCRIPTION REQ
101 PNL-024852-101 Release Rod 1
102 PNL-024852-102 Chain 1
103 PNL-024852-103 Adjusting Bolt 1
104 PNL-024852-104 Adjusting Nut 1
105 PNL-024852-105 Axle with Hole 1
106 PNL-024852-106 Elastic Pin 2
107 PNL-024852-107 Bushing 2
108 PNL-024852-108 Roller Pin 1
109 PNL-024852-109 Pressure Roller 1
109A PNL-024852-109A Bushing 1
110 PNL-024852-110 Draw-bar 1
111 PNL-024852-111 Stop Rubber 1
112 PNL-024852-112 Elastic Pin 1
113 PNL-024852-113 Blade Spring 1
114 PNL-024852-114 Spring 1
115 PNL-024852-115 Elastic Pin 1
116 PNL-024852-116 Elastic Pin 1
117 PNL-024852-117 Control Handle 1
118 PNL-024852-118 Roller 1
119 PNL-024852-119 Elastic Pin 1
121 PNL-024852-121 Pull Board 1
122 PNL-024852-122 Pin 1
201 PNL-024852-201 Fork Frame 1
202 PNL-024852-202 Elastic Pin 1
203 PNL-024852-203 Rock - Arm 1
204 PNL-024852-204 Bushing 2
205 PNL-024852-205 Shaft 2
206 PNL-024852-206 Bushing 2
207 PNL-024852-207 Bushing 2
208 PNL-024852-208 Retaining Ring 2
209 PNL-024852-209 Joint 2
210 PNL-024852-210 Pin 2
211 PNL-024852-211 Nut 2
212 PNL-024852-212 Push Rod 2
213 PNL-024852-213 Retaining Ring 2
214 PNL-024852-214 Shaft 1
215 PNL-024852-215 Bushing 4
216 PNL-024852-216 Shaft 2
217 PNL-024852-217 Intermediate Roller 4
218 PNL-024852-218 Extending Roller 2
219 PNL-024852-219 Elastic Pin 2
220 PNL-024852-220 Elastic Pin 4
221 PNL-024852-221 Shaft 2
222 PNL-024852-222 Frame of Roller 2
225 PNL-024852-225 Washer 8
231 PNL-024852-231 Bolt 2
232 PNL-024852-232 Enter Roller 2
233 PNL-024852-233 Locking Nut 2
234 PNL-024851-F1 Loading Roller w/ brg 2
235 PNL-024852-235 Shaft for Roller 2
236 PNL-024852-236 Washer 2
237 PNL-024852-237 Grease Cup 1
301 PNL-024852-301 Spring Cap 1
302 PNL-024852-302 Spring 1
303 PNL-024852-303 Pump Piston 1
304 PNL-024852-304 Dust Ring 1
305 PNL-024852-305 Seal 1
306 PNL-024851-129 Dust Cover 2
307 PNL-024852-307 Locking Ring 2
308 PNL-024852-308 Washer 2
309 PNL-024852-309 Bearing 4
310 PNL-024851-G Loading Wheel w brg 2
311 PNL-024852-311 Elastic Pin 1
312 PNL-024852-312 Elastic Pin 2
313 PNL-024852-313 Thrust Plate 1
314 PNL-024852-314 Retaining Ring 1
315 PNL-024852-315 Bearing 1
316 PNL-024852-316 Shaft of loading Wheel 1
317 PNL-024852-317 Nut 1
318 PNL-024852-318 Screw 1
319 PNL-024852-319 Lever Plate 1
320 PNL-024852-320 Elastic Pin 1
321 PNL-024852-321 Valve Cartridge 1
322 PNL-024852-322 Pump Body 1
323 PNL-024852-323 Seal Washer 1
324 PNL-024852-324 Screw Plug 1
325 PNL-024852-325 Seal 1
326 PNL-024852-326 O – Ring 1
327 PNL-024852-327 Dust Ring 1
328 PNL-024852-328 Piston Rod 1
329 PNL-024852-329 Steel Ball 1
330 PNL-024852-330 Screw Plug 1
331 PNL-024852-331 O - Ring 1
332 PNL-024852-332 Bolt 1
333 PNL-024852-333 Spring 1
334 PNL-024852-334 Spindle of Safety Valve 1
335 PNL-024852-335 Grease Cup 1
336 PNL-024852-336 Cylinder 1
337 PNL-024852-337 Cover of Bearing 1
