iTools GARDEN ITR52E - Page 35

35
Components list
1
Nylon line
2
Support cup
3
Cutting head
4
Blade guard
5
Rotation shaft tube
6
Handle fixing screw
7
Handle
8
Right handle
9
Throttle
10
Switch
11
Throttle lockout
12
Engine
13
Starter handle
14
Carburetor pump
15
Fuel tank
16
Throttle lever
17
Carrying strap holder
18
Left handle
Packaging content
1
Brush cutter 52CC EKO
1
Brush cutting blade
1
Nylon line cutting head
1
Cutting accessories support base
1
Cutting accessories fixing cover
1
Cutting accessories fixing nut
1
Set of screws
2
Hex key (4/5 mm)
1
Open end spanner (8/10 mm)
1
Combined slotted/phillips screwdriver
1
Spark plug wrench
1
Tools and accessories case
1
Fuel mixing container
1
Harness Strap
1
Instruction manual
TECHNICAL SPECIFICATIONS
Engine:
Combustion 2T
Power [kW/cv]:
1.6 / 2.15
Cylinder capacity [CC]:
52
Rotations [rpm]:
8500
Fuel:
Mix. – 1:40
Fuel tank [L]:
1
Autonomy [h]:
1.5
Shaft pipe length [mm]:
1500
Shaft pipe width [mm]:
26
Cutting blade width [mm]:
255
Width of cutting head with
nylon line [mm]:
440
Nylon line diameter [mm]:
2.4
Sound pressure level (L
PA
)
[dB(A)]:
100
Sound power level (L
WA
)
[dB(A)]:
114
Dimension [mm]:
1885 x 620 x 450
Weight [Kg]:
7.5
Simbology
Safety warnings and precautions.
All users must read the instruction manual to avoid
injuries.
No open flames and smoking.
Risk of electric shock.
Risk of burn.
Danger of injury.
Respect the safety distance.
Recycled material packaging.
