Vehicle power to the junction box
■
Junction box to the Mobile Collection vehicle dock
■
Junction box to the Mobile Collector radio
Mobile Collection does not use the auxiliary (AUX) outlet.
The following example shows an MC3 radio and sled for a laptop with all the power cables
connected.
ID Connection
(Label)
Description
1 Power in to
Mobile
Collector
radio
(POWER IN)
Power receptacle on Mobile Collector radio.
2 Auxiliary
outlet
(AUX)
Mobile Collection no longer uses the auxiliary outlet.
07 May 2020 815-0207-00 REV 000 Itron, Inc. Page 32 of 44
Vehicle Preparation and Hardware Installation Guide 3 Installing Mobile Collection Components
