Section 3. Making Connections
77-0100-001 12 September 2000
7 LAN RJ-45 Jack
With the built-in Ethernet LAN combo, you can make LAN connections without installing PC cards. Connection
speed is 10/100 Mbps. When using the LAN function, wrap your LAN cable around the EMI ferrite suppression box
to inhibit electromagnetic interference.
8 USB (Universal Serial Bus) Port
The Universal Serial Bus (USB) is the latest standard for attaching monitors, input devices, scanners, and other
devices to a PC. USB devices can be chained together on a single cable. USB is 1.1 compliant.
Left Side Connectors
1 PC-Card Slot
Use this slot to connect PCMCIA-card devices.
1
2 3
