IVAR SUPERAC 93 - Page 41

MODEL
SUPERAC
93 105 150 190 230 290 345 405
A 790 790 790 940 940 940 940 940 mm
B 1110
1110
1360
1405
1405
1655
1655
1905
mm
H 880 880 880 990 990 990 990 990 mm
A1 750 750 750 900 900 900 900 900 mm
Dimensions B1 760 760 1010
1010
1010
1260
1260
1510
mm
d 460 460 460 510 510 510 510 510 mm
e 430 430 430 465 465 465 465 465 mm
f 260 260 510 450 450 700 700 950 mm
r / m
2“ 2“ 2“ 65 65 65 65 65 DN
Fittings v 1”1/
4
1”1/
4
1”1/
4
1”1/
2
1”1/
2
1”1/
2
1”1/
2
1”1/
2
DN
s ¾” ¾” ¾” ¾” ¾” ¾” ¾” ¾” DN
∅ 200 200 200 220 220 220 220 220 mm
MODEL
SUPERAC
465 520 580 695 810 930 1045
A 1040 1040 1040 1240 1240 1240 1240 mm
B 1990 1990 2290 2345 2545 2545 2795 mm
H 1150 1150 1150 1280 1280 1280 1280 mm
A1 1000 1000 1000 1200 1200 1200 1200 mm
Dimensions B1 1512 1512 1812 1814 2014 2014 2264 mm
d 595 595 595 640 640 640 640 mm
e 625 625 625 625 625 625 625 mm
f 792 792 1092 974 1174 1174 1424 mm
r / m 80 80 80 100 100 100 100 DN
Fittings v 2” 2” 2” 65 65 65 65 DN
s ¾” ¾” ¾” ¾” ¾” ¾” ¾” DN
∅ 250 250 250 350 350 350 350 mm
MODEL
SUPERAC
1220 1450 1860 2330 2910 3490 4070
A 1380 1380 1610 1610 1800 1800 2000 mm
B 2950 3200 3245 3535 3955 4255 4790 mm
H 1500 1500 1800 1800 2000 2000 2210 mm
A1 1380 1380 1610 1610 1800 1800 2000 mm
Dimensions B1 2416 2666 2680 2970 3320 3620 4024 mm
d 810 810 965 965 1070 1070 1700 mm
e 430 430 430 430 510 510 522 mm
f 1700 1950 1440 1730 1700 2000 2200 mm
r / m 125 125 150 150 200 200 200 DN
