Control Panel
1. Power: On/Off/Operating/Standby
2. SELECT Button: Select ice cube size
3. WORK Indicator: Power on
4. ICE FULL Indicator: Ice basket is full
5. ADD Water Indicator: Reservoir is low
6. L / M / S Indicators:
Three selectable ice cube sizes:
L (large), M (medium), S (small); Default Setting is M
Operating Instructions
• Clean the machine before using. SEE “CLEANING” SECTION OF THIS GUIDE.
• Place the ice maker onto a smooth, flat surface in a well-ventilated area.
• Plug in the unit. IMPORTANT: WAIT 30 MINUTES BEFORE USING THE UNIT TO MAKE ICE FOR THE FIRST TIME.
THIS ALLOWS THE REFRIGERANT TO STABILIZE.
• Lift the cover, remove the ice basket, and pour fresh water into the water reservoir, filling to the top of the protrusions.
Press the power button.
• Select the desired ice cube size: S, M, L. The default size is M.
• The machine will make 9 ice cubes at a time. The process takes 7 – 10 minutes, depending upon the size of the ice
cubes selected, water temperature, and ambient temperature.
• Periodically check the “Add Water” indicator. If reservoir is empty, the machine will stop automatically. Make sure
the unit is turned off. Wait 3 minutes. Refill the water reservoir. Press the Power button to restart the unit.
• The machine will stop when the ice basket is full. Remove the basket and transfer the cubes to your freezer, cooler,
or ice bucket. This product is not intended to store ice.
• Replace the water in the reservoir every 24 hours. If the unit is not in use, drain any leftover water by removing the
screw cap and plug located at the back of the unit.
Parts & Controls
1. Transparent window
2. Cover
3. Operation panel
4. Air outlet
5. Air inlet
6. Power cord
7. Water drain outlet,
screw cap, and plug
8. Removable ice basket
9. Evaporator
10. Ice chamber
231
4 5
6
3
4
5
7
6
8
10
9
1
2
