TROUBLESHOOTING PROCEDURES (CONT’D)
Symptom Problem Solution
Not Spraying Loose needle chucking nut • Finger tighten (#16)
Needle stuck • Pull out/Break-free Needle (#4)
Improper air pressure • See specic compressor instructions
to raise or lower the air pressure
Paint too thick • See Paint Preparation
Clogged nozzle • Clean nozzle (#3) with toothpick
Cracked or damaged nozzle • Replace nozzle (#3)
Skipping Dried paint on needle tip (Tip-Dry) • See Cleaning the Needle
Paint too thick • See Paint Preparation
Dirty airbrush • See Cleaning the Airbrush Between Colors
• See Cleaning the Needle
Cracked or damaged nozzle • Replace nozzle (#3)
*Warning: The most likely time to damage the nozzle (#3) is upon removal from the airbrush.
