Iwata HP-C - MASTER PARTS LIST

— IWATA HP-C AIRBRUSH • MASTER PARTS LIST —
1 Needle Cap B I 110 2 n
2 Nozzle Cap 0.3 mm D I 140 3 n
0.4 mm D I 140 4 opt
3 Fluid Nozzle 0.3 mm G I 080 3 n
0.4 mm G I 080 4 opt
0.2 mm G I 085 2 opt
4 Fluid Needle 0.3 mm C I 075 3 n
0.4 mm C I 075 4 opt
5 Packing Fluid Needle (O-Ring) A I 150 2 n
6 Needle Packing Screw A I 125 1 n
7 Main Lever D I 100 2 n
8 Auxiliary Lever A I 040 4 n
9 Needle Chucking Guide C I 115 2 n
10 Needle Spring A I 135 3 n
11 Spring Guide C I 170 2 n
12 Valve Piston A I 175 1 n
13 Body* N/A n
14 Packing Air Piston (O-Ring) A I 145 1 n
15 Air Valve Set G I 030 4 n
15A Air Valve Guide A I 025 1 n
15B Air Valve Body D I 020 1 n
15C Air Valve B I 015 4 n
15D Air Valve Spring A I 035 1 n
16 Needle Chucking Nut A I 120 2 n
17 Handle E I 090 2 n
18 Pre-Set Handle G I 155 2 opt
25 Lid C I 095 4 n
Spanner A I 165 1 n
Conversion Kit (Converts 0.3 mm to
0.4 mm Nozzle - 4 Piece Conversion) I I 195 1 n
Crown Cap D I 105 0 opt
Quick Fit Set (QD Screws Onto Air Hose
and Adaptor Screws Onto Airbrush) I 160 3 opt
Quick Fit Adaptor
(Screws Onto Airbrush) I 160 4 opt
Adaptor (Iwata Airbrushes to
Paasche Airhose) J 001 opt
Adaptor (Iwata Airbrushes to
T & C/Badger Air Hoses) J 002 opt
n = yes x = no opt = optional n = yes x = no opt = optional
# Item Description Price Code Item# HP-C # Item Description Price Code Item# HP-C
15
*Replacement parts not available.
CA PROP
65
CA PROP
65
CA PROP
65
CALIFORNIA PROP 65 WARNING: Certain products identied with this symbol and oered for sale in this catalog contain lead,
a chemical known to the State of California to cause cancer, birth defects and other reproductive harm.
CA PROP
65
