C-R C-L
B
D
A
Note: Align Back Cushion (A) with Seat Cushion (B) by GENTLY inserting back support plate
into the rear hole of the Seat Plate (B) as shown and TIGHTEN by using 3 x screws (G).
Only applicable for when using a drill. Set torque to 5Nm. Before using your Chair,
ensure that all the Bolts are tightened fully for safety.
Note: Place assembled seat on the Gas Lift (D). Push down firmly until connection is secure.
G
I
G
3 Pcs
5/16" x 3/4" Bolt
used to complete
this step.
5/9
Torque 5 Nm
To Next Page
