J.Burrows TYPHOON PRO II - Page 4

Note: Turn the Star Base (G) upside down. Push the Castors (H) firmly into hole at the
end of each leg.Turn the Star Base (G) upside and insert Gas Lift (E) into the
center hole of Star Base (G).Place cover (F) over the Gas Lift (E).
F
E
G
H
4/10
Note: Align the Seat Plate (D) so the FRONT of the Seat Plate matches the FRONT
label on the bottom of the Seat Cushion (B). Tighten 4x Screws (M) with Allen
Key (P).
M
4 Pcs
used to complete
this step.
ø8x20mm
B
D
M
P
FRONT
