55..22. . LED indicatorLED indicator
LED indicator is located on the front cover of the unit. It provides a visual indication of unit's current status. During normal
operation green light pulses in regular intervals. A change in the LED color indicates an error notification, need to replace filters or
Bluetooth activation. All color indications are described in the following table.
Co l o r RGB LEDCo l o r RGB LED Descriptio nDescriptio n
green Constant power, Automatic mode, Stand-by
Yellow Replace filters! Filters are clogged!
Red Error! Fault!
Blue Active Bluetooth
Pleas e pay atte ntion to the changes in LED indicator.Pleas e pay atte ntion to the changes in LED indicator.
55..33. . Filters and filter replacementFilters and filter replacement
The heat recovery unit contains F7 filters at the air supply as well as exhaust. The need to replace the filters is indicated
automatically. Recommended frequency of their replacement depends on the air quality in the environment where the unit is
used (1× approx. 2 – 6 months). Basic filtration can be supplemented with an optional carbon filter, which is inserted directly into
the unit under the supplied air filter.
Users are alerted to the need to replace filters by:
a change of the color of LED indicator on the front side of the unit (see the preceding table),
a notification in MyJABLOTRON mobile application,
a notification "Filte r""Filte r" and a warning symbol on the control panel
Do not re ach into the filter s pace with your hands w hen replacing filters! Avoid the risk of handDo not re ach into the filter space w ith your hands w hen replacing filters! Avoid the risk of hand
injury!injury!
Never use your he at recove ry unit without filters ! The unit must be off during maintenance and filterNeve r us e your heat re covery unit without filters ! The unit must be off during maintenance and filter
re place ment!re place ment!
When replacing filters proceed as follows:
use On/Off button the switch the heat recovery unit off,
remove cover from filter drawer and pull filters out of the drawer,
insert a new filter into the drawer and place the cover back in its place, make sure to insert filters correctly, observing the
arrows indicating air flow direction!
switch the heat recovery unit on using the On/Off button
press filter initialization button on the control board (see fig. 4 – Filter initialization) or start filter replacement in
MyJABLOTRON application.
New filters mus t be inserted in both filte r draw ers and filte r covers must be place d back be foreNew filters mus t be ins erte d in both filter draw ers and filter covers mus t be placed back before
initialization proces s! Do not us e any other filters than those s upplied by the manufacturer and doinitialization proces s! Do not us e any other filters than those s upplied by the manufacturer and do
not add any extra prefilters !not add any extra prefilters !
