JA-160PC (90) PIR motion BUS detector with a 90° verification camera
JA-160PC (90) PIR motion BUS detector with a 90° verification camera 3 / 3 MMQ53102
batteries for new ones. Do not throw the batteries in the trash.
Deliver them to a civic amenity site instead.
FW upgrade
1. Remove at least one battery from the detector.
2. Run the F-Link software. Connect the USB cable with the mini USB
connector (13) inside the detector and then put back the battery
(or batteries) back.
3. Boot mode is indicated by the lit up red LED indicator and by short
flashing of the yellow LED.
4. Then continue the same way as if you were to upgrade the control
panel: Control panel ĺupgrade Firmware ĺFKRRVHWKH):SDFNILOH
ĺLQWKH ZLQGRZ ZKHUH \RX ZLOOEHRIIHUHG D GHYLFHWRXSJUDGH VHOHFW
the USB option and type of the device.
Technical specifications
Power 2x alkaline battery type LR6 (AA) 1.5 V
(alternatively 2x AA lithium battery, 1.5 V)
Typical lifetime about 2 years (1 activation and 1 series of photos a day)
Please note: Batteries are not included
Low battery voltage
- Alkaline batteries 2,52 V
- Lithium batteries 2,62 V
Recommended installation height 2.5 m above the floor
PIR Detection angle / detection coverage: 90°/12 m
Horizontal camera capture angle 90°
Range of the flash max. 3 meters
Resolution of the camera LQ 320x240; HQ 640x480 pixels
Photo size LQ/HQ (typically) 2-20 kB / 2-64 kB (6 kB / 35 kB)
Typical (LQ) photo transmission time to the control panel (ideally)
up to 20 sec. (10 sec.)
Typical (HQ) photo transmission time to the control panel (ideally)
up to 130 sec. (60 sec.)
Typical photo transfer time to the server 15 s/GPRS; 2 s /LAN
Dimensions, weight 110 x 60 x 55 mm, 102 g
Classification Security grade 2/Environmental class II
- according to EN 50131-1, EN 50131-2-2, EN 50131-5-3
- operational temperature range -10 to +40 °C
- operational environment indoor general
- certification body Trezor Test s.r.o. (no. 3025)
Also complies with ETSI EN 300 220, EN 50130-4,
EN 55022, EN 60950-1
Can be operated according to ERC REC 70-03
JABLOTRON ALARMS a.s. hereby declares that the JA-160PC
(90) is in a compliance with the relevant Union harmonisation
legislation: Directives No:
2014/53/EU, 2014/35/EU, 2014/30/EU,
2011/65/EU. The original of the conformity assessment can
be found at www.jablotron.com - Section Downloads.
Note: Although this product does not contain any harmful
materials we suggest you return the product to the dealer
or directly to the producer after use.
