The JA-81M wireless magnetic door detector & universal transmitter 2 MHQ53800_PTS
Testing the detector
15 minutes after closing the detector cover, the LED indicates detector
triggering. The strength and quality of detector signals can be measured
by the control panel in Service mode.
Battery replacement
The detector monitors its battery voltage and if too low, a transmission is
sent to the control panel to inform the installer or user. The detector
continues to function and shows each triggering of the detector with a flash
of its LED. Battery replacement should not be delayed by more than two
weeks. This should be done by a qualified technician with the control panel
in Service mode.
Expired batteries should not be thrown into the garbage, but disposed of
according to local regulations.
Removing the detector from the system
If a detector is removed, the control panel announces the removal. The
detector has to be deleted in the control panel before intentional removal.
Technical parameters
Voltage Lithium battery type LS(T)14500 (3.6V AA)
Typical battery lifetime approx. 3 years for 20 daily activations maximum
Communication band 868 MHz, Oasis protocol
Communication range approx. 300m (open area)
Typical sensitivity range of the built-in magnetic sensor 45 / 25mm
Inputs for external sensors IN2 and TMP = normally closed loops
IN1 normally closed or balanced loop (1k resistor)
The maximum length of the cable for external detectors 3 meters
Dimensions 110 x 31 x 26 mm
magnet: 56 x 16 x 15 mm
Operational environment according to EN 50131-1 II. Indoor general
Operational temperature range -10 to +40 °C
EN 50131-1,CLC/TS 50131-2-6, EN 50131-5-3 classification: grade 2
Complies with
ETSI EN 300220, EN50130-4, EN55022, and EN 60950-1
Can be operated according to ERC REC 70-03
Jablotron Ltd. hereby declares that the JA-80M is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC
CAUTION: Changes or modifications not expressly approved by Jablotron could void
the user´s authority to operate the equipment.
The original of the conformity
assessment can be found at www.jablotron.com
, Technical Support section
Note: Although this product does not contain any harmful materials we suggest you
return the product to the dealer or directly to the producer after use.
